Inclined Tube Settler is an efficient solid-liquid separation system designed for industrial wastewater and municipal sewage treatment.

Inclined Tube Settler is a high-efficiency solid-liquid separation equipment designed for industrial wastewater treatment and municipal sewage treatment applications. Based on the shallow sedimentation principle, this system uses specially arranged inclined tube modules to increase sedimentation efficiency, improve suspended solids removal performance, and achieve higher treatment capacity within a compact footprint. With a modular structure and flexible configuration options, the Inclined Tube Settler can be customized according to different flow rates, water quality conditions, and installation requirements, making it an ideal solution for both new wastewater treatment projects and existing system upgrades.

Customized Service

We provide complete solutions from process design and equipment manufacturing to installation, commissioning, and operation support. Our engineering team can develop customized Inclined Tube Settler solutions based on customer water quality analysis, site conditions, and treatment objectives.

Whether for a new wastewater treatment facility or an existing system upgrade, we help customers achieve efficient, reliable, and cost-effective solid-liquid separation performance.

1. High-Efficiency Sedimentation Performance

The Inclined Tube Settler significantly improves solid-liquid separation efficiency by increasing the effective settling area inside the tank. The inclined tube design creates shorter settling distances for suspended particles, allowing sludge particles to settle quickly and improving overall treatment performance.

Compared with conventional sedimentation tanks, this equipment provides higher surface loading capacity and better space utilization, making it suitable for projects requiring efficient wastewater treatment in limited areas.

2. Compact Design and Reduced Footprint

One of the major advantages of the Inclined Tube Settler is its space-saving design. The vertical arrangement of inclined tube modules maximizes sedimentation capacity without requiring large construction areas.

It is especially suitable for industrial facilities, municipal wastewater plants, and upgrading projects where available land is limited. By replacing or enhancing traditional sedimentation systems, customers can achieve increased treatment capacity without major expansion of the existing footprint.

3. Stable Operation and Low Maintenance

The Inclined Tube Settler adopts a simple mechanical structure with no complex moving components in the sedimentation zone, ensuring reliable operation and reducing potential equipment failures.

The inclined tube modules help promote automatic sludge sliding and collection, while the modular design allows individual sections to be removed for cleaning and maintenance. This reduces downtime and lowers long-term operating costs.

4. Flexible Customization Options

To meet different wastewater treatment requirements, the Inclined Tube Settler can be customized with various materials, module spacing, tank structures, and integrated treatment functions.

Available options include:

• Inclined tube materials: PVC, polypropylene, stainless steel, FRP and other materials

• Customized tube spacing based on suspended solids characteristics

• Carbon steel, stainless steel, or concrete tank structures

• Optional integration with flocculation zones and sludge thickening sections

The Inclined Tube Settler is widely used in various wastewater treatment industries, including:

Municipal Wastewater Treatment
Used for primary sedimentation upgrades, advanced treatment improvements, and expansion of existing wastewater treatment capacity.

Mining and Mineral Processing
Suitable for tailings wastewater treatment, mineral washing water recovery, and process water recycling.

Steel and Metallurgical Industry
Applied for steel rolling wastewater treatment, dust removal wastewater treatment, and circulating cooling water purification.

Petrochemical Industry
Used for oily wastewater pretreatment and recovery of valuable process materials.

Food and Beverage Industry
Suitable for starch wastewater, slaughterhouse wastewater, brewery wastewater, and other organic wastewater treatment applications.

Paper Industry
Applied for white water recovery, pulp concentration, and wastewater clarification.

Power Industry
Used for desulfurization wastewater treatment and ash flushing water purification.

Get a Quote

Please contact us directly and provide your project requirements. We will provide you with a detailed technical solution and quotation.
